Texas Tuff Rock Logs Product Description



Texas Tuff Rock Log nets filled with rock are a robust and permanent revetment for use around reservoirs, shorelines, lakes edges, streams and riverbanks.  They  are a tubular revetment consisting of small stones retained within a high strength polyethylene net.


The Rock Roll comes is 6'-7"long x 1' diameter (2 meter x 30cm).


The are cost-effective revetments that are suitable alternatives to riprap and gabions in many scour applications.


Texas Tuff Rock Logs  provide an instant flexible solution to many scour problems particularly below low water level where pure bioengineering techniques may not function.



They accrete silt due to small stone size and can be fully vegetated.


When joined together, Texas Tuff Rock Logs can form a Rock Mattress capable of resisting high velocities and shear stress up to 1200 N/m2 in high energy river situations.


When used in conjunction with coir rolls, coir pallets or live willow, Texas Tuff Rock Logs  provide a solution which can support a healthy invertebrate and even native crawfish populations.



Texas Tuff Rock Logs are used in all areas where vegetation alone will not provide sufficient erosion control.


Texas Tuff Rock Logs have been designed to provide invertebrate habitat and to accrete fine sediment to enable vegetation establishment within the stone interstices.


Texas Tuff Rock Logs  can be combined with bioengineering solutions to create a fully vegetated revetment.

Texas Tuff Rock Log Applications

Streams & Rivers

Rock Filter Dams during Construction

Streams & Rivers

 Texas Tuff Rock Logs  can be used within bioengineering  projects to form a robust toe that absorbs energy from water flow.   This allows the "living" elements of the bioengineering solution to establish in areas along the bank and minimize the erosion.  The small stone size in the Rock Rolls allows vegetation to easily establish and so the whole revetment becomes a vegetated system.

Shorelines

Rock Filter Dams during Construction

Streams & Rivers

When used in conjunction with  Texas Tuff Rock Logs, "living" bioengineering materials can be used in environments where energy level  from wave action would otherswise be too great.   They can be used in fresh and salt water.  Can be utilized with Texas Tuff Rock Bag and other products.

Rock Filter Dams during Construction

Rock Filter Dams during Construction

Rock Filter Dams during Construction

Temporary erosion, sediment and water pollution control measures during construction.   Texas Tuff Rock Logs  can be used at top of slope, at sediment trap, and at channel section.  Are an effective substitute for gabion sacks and mattresses.   Can be easy deployed and retrieved with minimum damage to surroundings.  Safe for worker.

Texas Tuff Rock Logs Benefits

An effective erosion control solution where vegetation alone will not provide sufficient protection.

Can replace large rock armor, concrete and rip rap. Use in salt and fresh water.

Flexible, contours to surface. Can be installed in flowing water.

Materials are long lasting - UV stabilized. Corrosion and abrasion resistant.

Easy to place. Can be picked up to be removed or reused.

Allows fine accretion of sediment to enable vegetation establishment

Texas Tuff Rock Log Filling & Installation

Texas Tuff Rock Logs Filling Process

Texas Tuff Rock Logs Installation Process

Texas Tuff Rock Logs Installation Process

The Rock Roll filling process is simple and efficent.   Is performed in a central location or onsite   The Rock Rolls can be transported for installation.

Send email to request Filling Process Summary.

Texas Tuff Rock Logs Installation Process

Texas Tuff Rock Logs Installation Process

Texas Tuff Rock Logs Installation Process

The  Texas Tuff Rock Logs installation process is simple and safe.  Once filled they are dropped into place.   They can be placed in moving water.   They are staked.   They can be linked together to make a more stable installation.
